Code parts Sub-
code
Section Value Meaning of the value
D Double modem (one modem is
the default)
M MID compliant energy output
metering
R Remote-resettable RCD for AC
output; needs Helios/backdoor
command (18Q1)
T Tilt sensor
H High current capable, for Terra
xx4 (up to 400 A in cabinet 1.1,
instead of 200 A in cabinet 1.0)
V: Customized design C Customized color for a specific
customer
D Customized design for a specif-
ic customer
<first
letters
of cus-
tomer
name>
Abbreviation of the customer
name
Example
TDC360 CE CCJJT 4L5-4N2 15DMBRW-180MT-0
• P1 = Terra, Brand = Terra
• P2 = DC 360, capacity is 360
• Q = CE, EVSE for the CE market
• R = CCJJT, EV charge cable connection = 2 x CCS and 2 x CHAdeMo and AC Type
2 socket 22 kW
• S1 = 4, the CCS EV cable length is 4 m
• S2 = L, the CCS EV cable is liquid cooled
• S3 = 5, the CCS EV cable rating is 500A
• S1 = 4, the CHAdeMo EV cable length is 4 m
• S2 = N, the CHAdeMo EV cable is non liquid cooled
• S3 = 2, the CHAdeMo EV cable rating is 200A
• T1 = 15, the touchscreen size is 15 in
• T2 = D, the EVSE has a display at the front and the rear side
• T3 = MB, the RFID reader can handle Mifare/NFC/Calypso and CCV payment
terminal with BSP (BS Payone)
• T4 = R, The EVSE has an advertisement screen on the front and the rear side
• T5 = W, the user operable elements of the EVSE are accesible for wheelchair
users
• U1 = 180, the maximum installed power is 180 kW
• U2 = MT, the EVSE has MID compliant energy output metering and tilt sensors
• V = 0, the EVSE is not customized for a specific customer
Technical data
96 9AKK108467A6398-EN | 002
