ABEM Terrameter LS
65
The event information starts with an error message over one or more lines describing
the problem and sometimes giving problem-solving examples. Then, normally, four
values are given:
― Tx: lists the electrodes involved in current transmitting
― Estimated load: the load as measured by the current transmitter
― Current: the transmitted current as measured by the current transmitter
― Status code: the status code number as well as one or more describing texts
The four commands behave like this:
― Stop measuring: The measurement stops. Works just like the stop command on
the Progress View
― Try again: The measurement is restarted from the failed data point. The error
dialog will be shown again if the error persists
― Accept this and continue: The data point is marked as failed and the
measurement is resumed with the next data point. The error dialog will be shown
again for the same type of error occurring later
― Accept this and all similar and continue: The data point is marked as failed and
the measurement is resumed with the next data point. The error dialog will not be
shown again for the same type of error occurring later in this measurement
A list of error messages follows:
Error message Comment
Emergency stop The Emergency Stop Button has been
pressed
Power source low voltage Check the internal and/or external
battery
Power source low capacity Check the internal and/or external
battery
Load resistance too high or No contact? Contact between LS and electrode(s)
might be bad. Check all contacts and
cables
Or
Contact between electrode(s) and
ground might be bad. Moisten the
ground around the electrode(s) with
salted water
No contact. Can not transmit current See Load resistance too high or No
contact (above)
Transmitter stopped due to unexpected high
power loss. Probable causes: A sudden drop
in resistance or a highly inductive load. Try
to reduce the maximum current
Stopped to prevent the transmitter from
being damaged. Try the proposed
action
