ABEM Terrameter LS

8.4 View and Export Data

Select the “File/Open Project” menu item to open a Project database in the project

data dialog (Figure 93). From this dialog it is possible to view the contents and export

data in different formats.

Note! If the opened Project is large then the actions described

in this chapter might be slow

Figure 93. Project data dialog

First select the Task to work with in the list. Performing actions on the selected Task

is then either done by right-clicking in the list and then selecting a menu item from the

pop-up menu:

Figure 94. Right-click pop-up menu
