EN - 5
MT/AUT/AUT RAB 2 Product Description
Type Type of
cooling
Load Duty
cycle
Wire
ø Gas flow Cooling data
dual
circiut
supply
temp
flow Flow pressure
CO
2
M21 max. min min. max.
MT A A % mm l/min °C l/min bar bar
555 W liquid 575 525 100 1,0 - 1,6 10 - 20 40 1,15 2,5 3,5
555 DW liquid 550 500 100 1,0 - 1,6 10 - 20 40 1,15 2,5 3,5
605 W liquid 625 575 100 1,0 - 1,6 10 - 20 40 1,15 2,5 3,5
605 DW liquid 600 550 100 1,0 - 1,6 10 - 20 40 1,15 2,5 3,5
Tab. 4 Product-specific torch data (EN 60 974-7) ABIMIG
®
MT
Type Type of
cooling
Load ED Wire  Gas flow Cooling data
Supply
temp.
Flow Flow
pressure
CO
2
M21 max. min. min. max.
AUT A A % mm l/min °C l/min bar bar
15 AK air 180 150 60 0.6 - 1.0 10 - 18
25 AK air 230 200 60 0.8 - 1.2 10 - 18
24 KD air 250 220 35 0.8 - 1.2 10 - 18
26 KD air 230 200 35 0.8 - 1.2 10 - 18
36 KD air 300 270 60 0.8 - 1.2 10 - 20
40 KD air 350 320 35 1.0 - 2.4 10 - 20
240 D liquid 300 270 100 0.8 - 1.2 10 - 20 40 1 2.5 3.5
401 D liquid 400 350 100 0.8 - 1.6 10 - 20 40 1 2.5 3.5
401 liquid 450 400 100 0.8 - 1.6 10 - 20 40 1 2.5 3.5
501 D liquid 500 450 100 1.0 - 1.6 10 - 20 40 1 2.5 3.5
501 liquid 550 500 100 1.0 - 1.6 10 - 20 40 1 2.5 3.5
602 liquid 600 550 100 1.0 - 1.6 10 - 20 40 1.3 2.5 3.5
Tab. 5 Product-specific torch data (EN 60 974-7) AUT
