EN - 18
10 Troubleshooting MT/AUT/AUT RAB
9.1 Hose assembly
See Fig. 3 Mounting the guide spiral liners on page EN-11
1 Unscrew the hose assembly (9) on the machine side and bring it into a
stretched position.
2 Unscrew union nut (3) and pull out guide spiral liner or PA liner and replace
it, if necessary.
3 Remove worn parts (10), (11) from the torch neck (2).
4 Clean wire feed hose (1) from both sides with compressed air.
5 Slide adjusted guide spiral liner or PA liner into wire feed hose (1) and
secure with union nut (3).
6 Connect hose assembly on the machine side with wire feed unit (4).
9.2 Torch neck
1 Remove gas nozzle.
2 Remove welding spatter and spray gas nozzle with the ABICOR BINZEL
antispatter agent.
3 Check wearing parts for visible damage and replace them, if required.
10 Troubleshooting
Risk of injury
Serious injuries caused by parts swirling around.
• When cleaning the wire guide with compressed air, wear suitable
protective clothing, in particular safety goggles.
• Some problems are listed below, with descriptions of possible causes
and solutions. If the measures described below are not successful, please
consult your dealer or the manufacturer.
• Please also consult the operating instructions for the welding
components, such as the power supply, welding torch system, re-
circulating cooling unit, etc.
