Abicor Binzel MIG - Technical Data

EN - 4
2 Product Description MT/AUT/AUT RAB
2.3 Technical Data
Transport and storage - 25 °C to + 55°C
Relative humidity up to 90 % at 20 °C
Tab. 1 Ambient temperature
Type of use automatic
Type of voltage DC
DC polarity of the electrodes Usually positive
Shielding gas (DIN EN ISO 14175) CO
2
and mixed gas M21
Wire types commercially available round wires
Voltage rating 141 V peak value
Protection type of the machine side
connections (EN 60 529)
IP2X
Tab. 2 General torch data (EN 60 974-7)
Type Type of
cooling
Load Duty
cycle
Wire ø Gas flow Cooling data
dual
circiut
DC Impulse Supply
temp
Flow Flow
pressure
CO
2
M21 M21 max. min min. max.
MT A A % mm l/min °C l/min bar bar
452 W liquid 500 500 325 100 1,0 - 1,6 10 - 20 50 1,0 2 3,5
452 DW liquid 450 450 300 100 1,0 - 1,6 10 - 20 50 1,0 2 3,5
645 W liquid 650 600 450 100 1,0 - 1,6 10 - 20 50 1,0 2 3,5
Tab. 3 Product-specific torch data (EN 60 974-7) ABIMIG
®
MT
