EN - 6
2 Product Description MT/AUT/AUT RAB
2.4 Abbreviations
2.5 Nameplate
The MIG/MAG welding torches are labelled at the machine-side connection
housing and at the torch neck. When making any inquiries, please remember
the following information:
• Production stamp on the torch neck, for example AUT401
Type Type of
cooling
Load ED Wire Gas flow Cooling data
Supply
temp.
Flow Flow
pressure
CO
2
M21 max. min. min. max.
AUT RAB A A % mm l/min °C l/min bar bar
36 KD air 300 270 60 0.8 - 1.2 10 - 20
501 D liquid 500 450 100 1.0 - 1.6 10 - 20 40 1 2.5 3.5
Tab. 6 Product-specific torch data (EN 60 974-7) AUT RAB
MT/AUT/AUT RAB
Standard length L 3.00 m, 4.00 m
Coolant connection Connector nipple NW 5
Cooling unit power min. 800 W
Tab. 7 Hose assembly data
DC Direct current
ED Duty cycle
MAG Metal Active Gas
MIG Metal Inert Gas
MT/AUT Automatic welding torch
AUT RAB Automatic welding torch with fume extraction
... AK Plug-in gas nozzle
... D Replaceable tip adapter
... KD Replaceable tip adapter
Voltage rating Classification of the insulation resistance, voltage strength and protection type
Tab. 8 Abbreviations
