ABL Wallbox eMH3 Installation Manual

| Appendix – Technical specifications
58
Model code 3W2263 3W2264
Backend communication LAN/LTE - OCPP 1.6 and 1.5, transport via SOAP or WebSockets
Compliance standards IEC 61851-1
Control / customisation Internal RS485 interface, bus system
Ambient temperature -30°C to 50°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95%, no condensation
Class of protection I
Degree of protection (housing) IP54
Overvoltage category III
Impact strength IK08
Dimensions (H×W×D)
492×394×189mm
(housing base incl. mounting plate, without overhangs)
Weight per unit approx. 13.5kg approx. 21kg
Extender Twin series (calibration law compliant)
Model code 3W2253 3W2254
Rated voltage 230/400V
Grid frequency 50Hz
Current 32A
Maximum output 2 × 11kW or 1 × 22kW
Charging connection Type 2 charging sockets, 2 pcs Type 2 charging cables, 2 pcs
Phase system 3-phase
Terminal blocks Direct connection to RCCB, PE to rail mount terminal block, max. 5 × 16mm²
Residual Current Devices RCCB, TypeA, 30mA
DC fault current detection
DC-RCM, I
Δn d.c.
≥ 6mA
Overcurrent protection
Integrated into firmware, disconnection at
110% after 100seconds, at 120% after 10seconds.
Energy meter MID compliant
Compliance module Logging Gateway (LGW)
Load switching Contactor, 4-pole
Weld detection Contactor welding switches off the charging point
RFID ISO14443A/B, UID (4 Byte/7 Byte) only
Backend communication via Controller wallbox
Compliance standards IEC 61851-1
Control / customisation Internal RS485 interface, bus system
Ambient temperature -30°C to 50°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95%, no condensation
Class of protection I
Degree of protection (housing) IP54
Overvoltage category III
Impact strength IK08
Dimensions (H×W×D)
492×394×189mm
(housing base incl. mounting plate, without overhangs)
Weight per unit approx. 13.5kg approx. 21kg
Controller Single series (calibration law compliant)
Model code 3W2260 3W2261
Rated voltage 230/400V

ABL Wallbox eMH3 Specifications

General

Model	eMH3
Manufacturer	ABL
Category	Automobile Battery Charger
Charging Power	22 kW
Number of Charging Points	1
Connector Type	Type 2
Installation	Wall-mounted
Communication	OCPP 1.6
IP Rating	IP54
Charging Current	32 A
Operating Temperature	-30°C to +50°C
Charging Power Options	Adjustable
Input Voltage	400 V
Output Voltage	400 V
