Configuring the Wallbox eMH3 – Configuration via software |
31
Extender 6 – 7 – 7 7 106
Extender 7 – 8 – 8 8 107
Extender 8 – 9 – 9 9 108
Extender 9 – 10 – 10 10 109
Extender 10 – 11 – 11 11 110
Extender 11 – 12 – 12 12 111
Extender 12 – 13 – 13 13 112
Extender 13 – 14 – 14 14 113
Extender 14 – 15 – 15 15 114
Extender 15 – 16* – 16* 16* 115
*The upper limit address value of 16 has been reached.
The allocation of addresses may be carried out either manually or automatically (recommended) via the ABL Con-
figuration Software: Please read the ABL Configuration Software manual, which is contained in the installation
folder of the software and also embedded in the application.
Configuration via software
The functional set-up of Controller and Extender wallboxes is carried out via the ABL Configuration and Charge
Point Administration software applications.
ABL Configuration Software
The ABL Configuration Software is an application for Windows PCs, and is used to set up the following wallbox
parameters:
Automatic allocation of bus addresses to charge controllers, energy meters, RFID modules, and to logging gate-
ways/calibration law compliance modules (calibration law compliant charging stations only)
Manual allocation or change of bus addresses
Setting an Extender charging station up for stand-alone operation
Setting up a maximum current and activating load imbalance detection
(De)activating the internal load management
(De)activating the RFID access restriction
Management of RFID cards
Enabling/locking the charging station
Software access
Free download at www.ablmobility.de
Description
Separate manual embedded in the application, and also contained in the installation folder.
Charge Point Administration
Charge Point Administration is an application embedded in the Single Board Computer (SBC) of the Controller wall-
box, which is opened via the browser application of a Windows PC, and serves to set up the following and additional
parameters for the group installation:
Setting up system configuration
Setting up static or dynamic load management for the system
Displaying and setting up OCPP configuration
Backend connection
Displaying system status information
Displaying wallbox parameters in the group
