Abus Smartvest User Manual

26
English
FUBW35000 PIR Motion Detector
The motion detector is only suitable for indoor use. For further information, please refer to the safety
instructions relating to installation location and operating environment.
General installation instructions
 Install the motion detector 2–2.5 m above the ground for a range of 12 m.
 Install the detector either flush to the wall or in a corner (recommended).
 Do not install the motion detector opposite heat sources or windows, above a radiator, close to
large metallic structures, close to power cables or gas lines, close to electronic or wireless
equipment, or closer than 30 mm to the ceiling.
 The detector's detection range is directed downwards. For this reason, do not tilt the detector too
sharply downwards, as otherwise the range will be restricted. A horizontal, upright position is
recommended.
Adhesive installation
1. For wall installation, stick the adhesive pads provided on to the rear of the motion detector.
2. For corner installation, stick the adhesive pads on to the motion detector's chamfers (angled
surfaces).
3. Install the motion detector in the desired installation location on a flat surface.

Abus Smartvest Specifications

General

Certification	CE, GS
Maximum power	3680 W
Product color	White
LED indicators	Yes
AC input voltage	250 V
Connector gender	Male/Female
Housing material	Acrylonitrile butadiene styrene (ABS)
Sockets quantity	1
Plug connector type	Type F
Maximum indoor range	30 m
Maximum outdoor range	100 m
RF transmission frequency	868 MHz

Weight and Dimensions

Depth	31 mm
Width	55 mm
Height	99 mm
Weight	129 g
