Abus Smartvest User Manual

27
English
Drill installation using bracket
1. Press the bracket into the motion detector.
2. Hold the motion detector next to the desired installation location and adjust to the desired angle.
3. Fix the position by tightening the screw on the rear of the bracket.
4. Stick the motion detector's drilling template in the desired installation location. Use a spirit level to
ensure the drilling template is straight. Drill holes in the specified positions and insert the screw
anchors provided.
Remove the bracket and fix it in place using the screws provided. Finally, press the motion detector
back on to the bracket.
Drill installation without bracket
1. Press the catch on the underside of the motion detector and remove the motion detector's rear
panel.
2. Use the holes provided on the inside of the rear panel as a drill template for wall or corner
installation.
3. Drill the holes and insert the screw anchors provided. Next, screw the motion detector's rear panel
into the wall or corner using the screws provided.
4. Press the motion detector back on the fitted base plate of the motion detector.
FURM35000 smoke alarm/heat detector
The smoke alarm/heat detector is only suitable for indoor use. For further information, please refer to
the safety instructions relating to installation location and operating environment and to the instructions
for the smoke alarm/heat detector.
Installation
Refer to the instructions for the smoke alarm/heat detector for installation.

Abus Smartvest Specifications

General

Certification	CE, GS
Maximum power	3680 W
Product color	White
LED indicators	Yes
AC input voltage	250 V
Connector gender	Male/Female
Housing material	Acrylonitrile butadiene styrene (ABS)
Sockets quantity	1
Plug connector type	Type F
Maximum indoor range	30 m
Maximum outdoor range	100 m
RF transmission frequency	868 MHz

Weight and Dimensions

Depth	31 mm
Width	55 mm
Height	99 mm
Weight	129 g
