Accu-Chek ACTIVE User Manual

24
Testing blood glucose
4
1
As long as the test result is being displayed on the display, you can
mark the test result.
Press the S button or M button repeatedly until the desired marker is
displayed.
When you press the S button, the markers appear in the following
order: 1 Before meal; 2 Test reminder; 3 After meal; 4 Other;
5Control.
The respective marker appears below on the display
1
.
When you press the M button, the markers appear in the reverse
order.
If you decide to not mark the test result, press the S button or M
button repeatedly until no further symbol is displayed.
In the example above, the Before
meal marker ( symbol) was
selected.
After choosing the desired
marker, you can turn the meter
o.
The test result is saved together
with the marker.
2
mg/dL
meter
mmol/L
meter
Control
Other
After meal
Before meal
No marker
Test reminder
1

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
