2
1.1 Meter Overview
Powerful Multifunction Power Meter
The Acuvim II series multifunction digital power meter is designed using
modern MCU and DSP technology. It integrates three-phase energy measuring
and displaying, energy accumulating, power quality analysis, malfunction
alarming, data logging and network communication. A vivid LCD display with
large characters and, time of use programmable backlight provides a clear real-
time data readout.
An Ideal for Electric Automation SCADA Systems
The Acuvim II series meter is the ideal choice for replacing traditional, analog
electric meters. In additon to providing clear real-time readings on the meter
front, it can also be used as a remote terminal unit (RTU) for monitoring and
controlling for a SCADA system. Users can access all measurement parameters
via the standard RS485 communication port (or the optional Ethernet port) with
the Modbus
TM
protocol.
Energy Management
The Acuvim II series meter is able to measure bidirectional, four quadrants
kWh and kvarh. It provides maximum/minimum records for power usage and
power demand parameters. All power and energy parameters can be viewed
remotely via software in order to easily monitor various parameters. In addition,
measurement tables can be viewed from the free Acuview software.
Remote Power Control
This meter is designed for measuring and monitoring power quality parameters.
Since different I/O modules can be added to the meter, this expands the
capabilities and provides a very flexible platform for using the meter as a
distributed RTU, for metering, monitoring and remote controlling, all in one unit.
