337
Appendix B Ordering Information
Acuvim II series meter:
5A: 5Amp
1A: 1Amp
333mv: (Voltage type)
100mV/120mV(Rope-CT)
mA(80mA/100mA/200mA)
50: 50Hz
60: 60Hz
400: 400Hz
Acuvim II
Acuvim IIR
Acuvim IIE
Acuvim IIW
Current Input Power SupplyFrequency
Acuvim II
D: Standard with LCD display
M: DIN rail mount (no LCD)
P1: 100-415Vac, 50/60Hz
100-300Vdc
P2: 20-60Vdc
DIN Rail Option
Acuvim II Base Meter Ordering Example: Acuvim IIR - D - 60 - 5A - P1
