250
Setting
value
Alarming object
Setting
value
Alarming object
Setting
value
Alarming object
33
THD_V1(V1 or
V12)
34
THD_V2(V2 or
V31)
35 THD_V3(V3 or V23)
36 Average THD_V 37 THD_I1 38 THD_ I2
39 THD_ I3 40
Average
THD_I
41 AI1 sampling value
42
AI2 sampling
value
43
AI3 sampling
value
44 AI4 sampling value
45
Active power
demand of all
46
Reactive power
demand of all
47
Apparent power
demand of all
48
Current demand
of phase A
49
Current demand
of phase B
50
Current demand of
phase C
51
reversed phase
sequence
52~79 DI1~DI28
Note:
1. When reversed phase sequence (51) is selected, whether the value of
comparison mode or setpoint value is set or not doesn’t aect alarm result and
angle of Ub to Ua will be recorded.
2. When DI (52~79) is selected, whether the value of comparison mode is set or
not doesn’t aect alarm result and as long as setpoint value is set to 1, 2 or 3.
1 stands for DI alarm is from OFF to ON, and recovery is from ON to OFF.
2 stands for DI alarm is from ON to OFF, and recovery is from OFF to ON.
3 stands for DI alarm from ON to OFF, and recovery is from OFF to ON, and
present DI status is recorded.
6.3.5 I/O Modules Settings
I/O module setting changes will be made only if the corresponding I/O modules
are installed, no changes will be made otherwise. Please check the I/O module
connection status before doing any settings. Function code: 03H for reading,
10H for writing. Please refer to Chapter 5 Extended Modules for more details.
