AccuEnergy Acuvim II series User Manual

251
AXM-IO11
Table 6-21
Address Parameter Default Range Data type Property
109EH DI1~6 type 0
Bit0: DI1, Bit1: DI2
Bit2: DI3, Bit3: DI4
Bit4: DI5, Bit5: DI6
0: DI,1: pulse counter
word R/W
109FH DI pulse constant 0 1~65535 word R/W
10A0H
Working mode of relay 1
and 2
0
0: control output,
1: alarming output
word R/W
10A1H
Output mode of relay 1
and 2
0 0: latch, 1: pulse word R/W
10A2H Pulse width 50 50~3000ms word R/W
AXM-IO21
Table 6-22
Address Parameter Default Range Data type Property
10A3H DI7~10 type 0
Bit0: DI7, Bit1: DI8
Bit2: DI9, Bit3: DI10
0: DI,1: pulse counter
word R/W
10A4H DI pulse constant 0 1~65535 word R/W
10A5H Working mode of DO 0
0: pulse output
1: alarming output
word R/W
10A6H DO pulse width 20 20~1000ms word R/W
10A7H DO1 output 0
0: none
1: consumption power
2: gererating power
3: absorption reactive power
4: generating reactive power
word R/W
10A8H DO2 output 0 Same as above word R/W
10A9H AO1,2 type 1 or 2
0: 0~20mA, 1: 4~20mA,
2: 0~5V, 3: 1~5V
word R/W
