AccuEnergy Acuvim II series User Manual

252
AXM-IO31
Table 6-23
Address Parameter Default Range Data type Property
10AAH DI11~14 type 0
Bit0: DI11,Bit1: DI12,
Bit2: DI13, Bit3: DI14
0: DI, 1: pulse counter
word R/W
10ABH DI pulse constant 0 1~65535 word R/W
10ACH
Working mode of relay 3
and 4
0
0: control output,
1: alarming output
word R/W
10ADH
Output mode of relay 3
and 4
0 0: latch, 1: pulse word R/W
10AEH Pulse width 50 50~3000ms word R/W
10AFH AI1,2 type 1 or 2
0: 0~20mA, 1: 4~20mA,
2: 0~5V, 3: 1~5V
word R/W
AXM-IO12
Table 6-24
Address Parameter Default Range Data type Property
10B0H DI15~20 type 0
Bit0: DI15, Bit1: DI16,
Bit2: DI17, Bit3: DI18,
Bit4: DI19, Bit5: DI20
0-DI,1-pulse counter
word R/W
10B1H DI pulse constant (high) 0 1~65535 word R/W
10B2H
Working mode of relay 5
and 6
0
0: control output,
1: alarming output
word R/W
10B3H
Output mode of relay 5
and 6
0
0: latch,
1: pulse
word R/W
10B4H Pulse width 50 50-3000ms word R/W
