3.3 Statistics Data
Pressing H and V/A simultaneously will activate the display mode selection and the cursor will
flash. Press P or E to move the cursor right or left. To enter the statistics data mode, scroll the
cursor to "Max/Min" then press V/A.
In statistics data mode, the meter displays the maximum values and minimum values
for voltage, current, power, power factor, unbalance, demand, THD etc. User should
note that time stamp for the parameters can be viewed only from the software through
communication. No commands are associated with the key H in "Max/Min" display mode.
When P is pressed again, the screen will roll to the next page, and will roll back to the first
screen when pressed at the last page.
When E is pressed the screen will roll back to the previous page, and will roll back to the last
screen when pressed at the first page.
Press V/A to switch the view between maximum and minimum. For example, if the current
display is the maximum phase voltage value, when V/A is pressed, the display
will show the minimum phase voltage value. If V/A is pressed again, the display
will switch back to show the maximum phase voltage value.
The following gure shows the sequence:
