AccuEnergy Acuvim II series User Manual

30
Detailed human-machine interface of the meter will be described in this
chapter. This includes viewing real-time metering data and setting parameters
using dierent key combination.
3.1 Display Panel and Keys
The front of the Acuvim II series meter consists of an LCD screen and four control
keys. All the display segments are illustrated in Fig 3-1. Users should note that
all the segments will not display in a single page under normal conditions.
Fig 3-1 All Display Segments
9
11
12
13
14
15
16
17
1
4
5
6
7
8
2
3
10
