41
Note:
i) The gure shows the rolling sequence when pressing P. The sequence will be
reversed when pressing E.
ii) When the meter is set to “2LL” or “3LL”, the first screen(max value of phase
voltage) will not be displayed.
iii) When the meter is set to “1LL”, there are no such displays as phase C voltage,
Ubc and Uca line voltage, phase C current, three phase voltage and current
unbalance factor, Uc and Ic THD, phase C current demand, etc.
iv) When the meter is set to “1LN”, there is only phase A display of phase voltage
and current, only Ua and Ia THD display, only demand display of phase A. And
there are no such displays as three phase voltage and current unbalance factor,
line voltage, etc.
Max value of phase
voltage
Max value of the line
to line voltage
Max value of current
Max value of power
Max value of power
factor & frequency
Max value of
unbalance factor
Max value of current
demand
Max value of current
THD
Max value of voltage
THD
Max value of Power
Demand
