AccuEnergy Acuvim II series User Manual

253
AXM-IO22
Table 6-25
Address Parameter Default Range Data type Property
10B5H DI21~24 type 0
Bit0: DI21, Bit1: DI22,
Bit2: DI23, Bit3: DI24
0: DI, 1: pulse counter
word R/W
10B6H DI pulse constant 0 1~65535 word R/W
10B7H
Working mode of
DO3,4
0
0: pulse output,
1: alarming output
word R/W
10B8H DO Pulse width 20 20~1000ms word R/W
10B9H DO3 output 0
0: none
1: consumption power
2: gererating power
3: absorption reactive
power
4: generating reactive
power
word R/W
10BAH DO4 output 0 Same as above word R/W
10BBH AO3,4 type 1 or 2
0: 0~20mA, 1: 4~20mA,
2: 0~5V, 3: 1~5V
word R/W
AXM-IO32
Table 6-26
Address Parameter Default Range Data type Property
10BCH DI25~28 type 0
Bit0: DI25, Bit1: DI26,
Bit2: DI27, Bit3: DI28
0: DI, 1: pulse counter
word R/W
10BDH DI pulse constant 0 1~65535 word R/W
10BEH
Working mode of relay
7 and 8
0
0: control output,
1: alarming output
word R/W
10BFH
Output mode of relay
7 and 8
0 0: latch, 1: pulse word R/W
10C0H Pulse width 50 50~3000 word R/W
10C1H AI3,4 type 1 or 2
0: 0~20mA, 1: 4~20mA,
2: 0~5V, 3: 1~5V
word R/W
