AccuEnergy Acuvim II series User Manual

336
Communication
RS-485 (Standard)
2-wire connection
MODBUS RTU Protocol or DNP3.0 Protocol
Up to 38400 baud rate
Ethernet (Optional)
10M/100M BaseT
MODBUS TCP/IP Protocol
Data Browsing through HTTP
Sends e-mail automatically
PROFI-BUS (Optional)
PROFIBUS-DP/V0 Protocol
Work as PROFIBUS slave, baud rate adaptive, up to 12M
Model 1:Input Bytes 32,Output Bytes: 32
Model 2:Input Bytes 64,Output Bytes:2
PROFIBUS standard according to EN 50170 vol.2
RS-485 (Optional):
2-wire connection
MODBUS RTU Protocol
Up to 38400 baud rate
BACnet MS/TP(Optional) 2-wire connection BACnet Protocol
BACnet IP(Optional) RJ45 BACnet Protocol
