AccuEnergy Acuvim II series User Manual

335
Suitable Conditions
Dimensions (mm)
96x96x51
(Cut-out 92x92 or 4-inch Round)
Protection Level IP54 (Front), IP30 (Cover)
Weight (g) 350g
Temperature
-25°C~70°C, Metering
-40°C~85°C, Storage
Humidity 5%~95% Non-condensing
Power Supply
100~415Vac, 50/60Hz; 100~300Vdc
Category III, Pollution degree 2
Power Consumption 5W
Standard Compliance
Measurement Standard IEC 62053-22; ANSI C12.20
Environmental Standard IEC 60068-2
Safety Standard IEC 61010-1, UL 61010-1
EMC Standard IEC 61000-4/-2-3-4-5-6-8-11, CISPR 22
Outlines Standard DIN 43700, ANSI C39.1
