I/O Option
Digital Input
Input Voltage Range 20~160Vac/dc
Input Current (Max) 2mA
Start Voltage 15V
Stop Voltage 5V
Pulse Frequency (Max) 100Hz, 50% Duty Ratio
SOE Resolution 2ms
Digital Output (DO) (Photo-MOS)
Voltage Range 0~250Vac/dc
Load Current 100mA(Max)
Output Frequency 25Hz, 50% Duty Ratio
Isolation Voltage 2500Vac
Relay Output (RO)
Switching Voltage (Max) 250Vac,30Vdc
Load Current 5A(R), 2A(L)
Set Time 10ms (Max)
Contact Resistance 30mΩ(Max)
Isolation Voltage 2500Vac
Mechanical Life 1.5×10
7
Analog Output (AO)
Output Range 0~5V/1~5V, 0-20mA/4~20mA(Optional)
Accuracy 0.5%
Temperature Drift 50ppm/°C typical
Isolation Voltage 500Vdc
Open Circuit Voltage 15V
Analog Input (AI)
Input Range 0~5V/1~5V, 0~20mA/4-20mA (Optional)
Accuracy 0.2%
Temperature Drift 50ppm/°C typical
Isolation Voltage 500Vdc
Power Supply for DI (24Vdc)
Output Voltage 24Vdc
Output Current 42mA
Load (Max) 21DIs
