AccuEnergy Acuvim II series User Manual

333
Accuracy
Parameters Accuracy Resolution Range
Voltage 0.2% 0.1V 10V~1000kV
Current 0.2% 0.001A 5mA~50000A
Power 0.2% 1W -9999MW~9999MW
Reactive Power 0.2% 1Var -9999MVar~9999MVar
Apparent Power 0.2% 1VA 0~9999MVA
Power Demand 0.2% 1W -9999MW~9999MW
Reactive Power Demand 0.2% 1Var -9999MVar~9999MVar
Apparent Power Demand 0.2% 1VA 0~9999MVA
Power Factor 0.2% 0.001 -1.000~1.000
Frequency 0.2% 0.01Hz
45.00~65.00Hz (50Hz or 60Hz type)
300.00~500.00 (400 type)
Energy
Primary 0.2% 0.1kWh 0~99999999.9kWh
Secondary 0.2% 0.001kWh 0~999999.999kWh
Reactive Energy
Primary 0.2% 0.1kvarh 0~99999999.9kvarh
Secondary 0.2% 0.001kvarh 0~999999.999kvarh
Apparent Energy
Primary 0.2% 0.1kVAh 0~99999999.9kVAh
Secondary 0.2% 0.001kVAh 0~999999.999kVAh
Harmonics 1.0% 0.1% >=0.0%
Phase Angle 2.0% 0.1° 0.0°~359.9°
Imbalance Factor 2.0% 0.1% 0.0% ~ 100%
Running Time <1second/day 0.01h 0~9999999.99h
Temperature Drift <100ppm/°C
0.5‰/year
Control power
AC/DC Control Power
Operating Range 100~415Vac, 50/60Hz; 100~300Vdc
Burden 5W
Withstand 3250Vac, 50/60Hz 1min
Installation Category III (Distribution)
Low Voltage DC Control Power (Optional)
Operating Range 20~60Vdc
Burden 5W
