As long as seal is in sealed status, parameters below must be blocked, no matter
what value of address 101EH.
System parameters setting:
Address Parameter Keys Communication
1003H Voltage input wiring type √ √
1004H Current input wiring type √ √
1005H PT1(High 16 bit) √ √
1006H PT1(Low 16 bit) √ √
1007H PT2 √ √
1008H CT1 √ √
1009H CT2 √ √
100AH kWh pulse constant √ √
100BH Kvarh pulse constant √ √
100DH Demand slid window time √ √
100EH Demand calculating mode √ √
100FH Clear demand memory √ √
1012H Current I1 direction √ √
1013H Current I2 direction √ √
1014H Current I3 direction √ √
1015H VAR/PF convention √ √
1016H Energy clear √ √
1017H Energy calculating mode √ √
1018H
Reactive power measuring
mode
√ √
1019H Energy display mode √ √
101DH Basic parameter mode √ √
101EH
Sealed Nonstandard
Parameters Selection
- √
Note: “√” means these addresses will be blocked for keys and communication,
and”-“ means this function is unavailable.
To Next Page
