107
10BAH DO4 output √ √
Sealed Nonstandard Parameters:
1) When bit 0 of address 101EH is valid, parameters about 1
st
communication
should be blocked.
Address Parameter Keys Communication
0FFEH Communication Protocol 1 √ √
0FFFH Parity Setting 1 √ √
1000H Password √ √
1001H Communication address 1 √ √
1002H Baud rate 1 √ √
2) When bit 1 of address 101EH is valid, parameters about 2
nd
communication
should be blocked.
Address Parameter Keys Communication
102FH Baud rate2 √ √
1030H Parity Setting 2 √ √
1031H Communication address 2 √ √
Ethernet Module
DHCP setting √ √
IP address 1
st
byte (high) √ √
IP address 2
nd
byte (low) √ √
IP address 3
rd
byte (high) √ √
IP address 4
th
byte (low) √ √
Submask 1
st
byte (high) √ √
Submask 2
nd
byte (low) √ √
Submask 3
rd
byte (high) √ √
Submask 4
th
byte (low) √ √
Gateway 1
st
byte (high) √ √
Gateway 2
nd
byte (low) √ √
Gateway 3
rd
byte (high) √ √
Gateway 4
th
byte (low) √ √
DNS1 1
st
byte (high) √ √
DNS1 2
nd
byte (low) √ √
DNS1 3
rd
byte (high) √ √
