166
Response
The normal response to the command request is to retransmit the message as
received after the Relay status has been altered.
Table 5-13 Control Relay Response Message
Transaction
identier hi
Transaction
identier lo
Protocol
identier hi
Protocol
identier lo
Length hi Length lo
Unit
identier
00H 00H 00H 00H 00H 06H 01H
Fun Data start reg hi Data start reg lo Value hi Value lo
05H 00H 00H FFH 00H
e. Preset/Reset Multi-Register (Function Code 16)
Query
Function code 16 allows the user to modify the contents of a Multi-Register. The
example below is a request to an Acuvim II series meter address 1 to Preset CT1
(500) and CT2 (5). CT1 data address is 1008H, and CT2 data address is 1009H.
Table 5-14 Preset CT Value Query Message
Transaction
identier hi
Transaction
identier lo
Protocol
identier hi
Protocol
identier lo
Length hi Length lo
Unit
identier
00H 00H 00H 00H 00H 0BH 01H
Fun
Data start
reg hi
Data start
reg lo
Data #of
regs hi
Data #of
regs lo
Byte
count
Value1
hi
Value1
lo
Value2
hi
Value2
lo
10H 10H 08H 00H 02H 04H 01H F4H 00H 05H
Response
The normal response to a preset Multi-Register request includes MBAP Header,
function code, data start register and the number of registers.
