179
"Harmonics"webpage includes harmonics parameters for Acuvim II series meter,
such as THD Volts Average.
"Sequence" webpage includes the sequence and angle parameters for Acuvim
II series meter. There are fteen parameters, such as positive sequence of VA,the
angle VB to VA.
"Max and Min" webpage includes the max and min data of parameters for
Acuvim II series meter. There are twenty-ve parameters, such as Volts AN, I A ,
and Watt Total (Demand).
"Alarm Record" webpage includes alarm records for Acuvim II series meter. There
are sixteen records. Each record includes Time Stamp, Limit ID,Status, Alarm
Channel and Value.
"SOE Record" webpage includes SOE record for Acuvim II series meter. There are
twenty records. Each record includes Time Stamp, DI Status.
"IO Status" webpage includes DI status or DI counters, DO status, RO status,
Analog Input values and Analog Output values.
5.2.12 Email Function
The Ethernet module supports SMTP protocol, which provides email capabilities.
Before sending emails, users must set their own DNS Server. Please refer to
"Network settings"which includes DNS Server setting.
Please note, as per 3.c of Section 5.2.11, there are four modes users can select.
The first is "Trigged Sending", which means once new events happen, users
can receive email notifications immediately. The second is "Timed Sending"
mode. Users can receive emails based on preset time invervals (5~1440
minutes), which include all information on "Data" webpage. The third mode is a
combination of "Triggered Sending" and "Timed Sending". The fourth mode is
disable both "Triggered Sending" and "Timed Sending".
