284
• Compute the next expected record oset by adding Records Per Window and
go to step 2.
• If there are no remaining records after the current record window, stop
reading.
6.3.9 Time of use
Data address of TOU energy
The data address save the parameter of energy, which includes Data address
of last month TOU energy, Data address of current month TOU energy, Data
address of TOU parameter setting and Data address of TOU default parameter.
Except for the data address of TOU default parameter, the data address is read
with 03 code, preset with 16 code.
Data address of
TOU energy
Data address of current
month accumulation TOU
Data address of TOU
parameter setting
Data adress of TOU
default parameter
Basis parameter of TOU
Season parameter setting of TOU
Schdule setting of TOU
Holiday setting of TOU
Basis default parameter of TOU
Season default parameter setting of TOU
Schedule default setting of TOU
Holiday default setting of TOU
Fig 6-1 Division plan of TOU energy
Data address of prior
month accumulation TOU
Data address of prior
month TOU
Data address of current
month TOU
