309
Table 6-55
Address Parameter
Data
Type
Property Range Default
Factory
Setting
8000H
Manual
Triggering
Waveform
word R/W
0XAA:Enable;
0:Disable
0 0
8001H
DI Triggering —
AXM-11
word R/W
bit1bit0: DI1; bit3bit2:
DI2; bit5bit4: DI3;
bit7bit6: DI4; bit9bit8:
DI5; bit11bit10: DI6;
00: Disable;
01: From OFF to ON;
10: From ON to OFF;
11: Any DI state
change;
0 0
8002H
DI Triggering —
AXM-21
word R/W
Bit1bit0: DI7; bit3bit2
: DI8; bit5bit4: DI9;
bit7bit6: DI10;
The same as above
0 0
8003H
DI Triggering —
AXM-31
word R/W
Bit1bit0: DI11;
bit3bit2 : DI12;
bit5bit4: DI13;
bit7bit6: DI14;
The same as above
0 0
8004H
Voltage Rated
Value
word R/W
50V – 400V or
50V – 690V (only in
3LL)
400 400
8005H
Voltage Sag
Triggering
Waveform
word R/W
1: Enable;
0: Disable
0 0
8006H
Voltage Sag
Threshold
word R/W 20---100(%) 50 50
8007H
Voltage Sag half
cycle count
word R/W 4-200 half cycles 10 10
