Acer Aspire One D270 Series - Microphone Removal

Machine Maintenance Procedures 3-33
Microphone Removal 0
Prerequisite:
LCD Bezel Removal
1. Find the microphone (A) on the LCD module (Figure 3-33).
Figure 3-33. Microphone and Camera Module Locations
2. Remove the microphone from the LCD module as shown in Figure 3-34.
NOTE:
NOTE:
Use care not to damage the microphone.
Figure 3-34. Microphone Removal
C
A
B
B
