Machine Maintenance Procedures 3-41
Camera Module Removal 0
Prerequisite:
LVDS Cable Removal
1. Find the camera module (D) on the LCD module. Refer to Figure 3-33.
2. Remove the camera module from the LCD cover as shown in Figure 3-43.
Figure 3-43. Camera Module Removal
Camera Module Installation 0
1. Place the camera module on the LCD module. Refer to Figure 3-43.
2. Install the LVDS cable.
