- 29 -
E-MILL 6VK MACHINE SPECIFICATIONS:
Range
Table Travel (X-axis)
59” Table: 47 1/4”/
1200mm
Saddle Travel (Y-axis)
15 in. (381mm)
Quill Travel
5 in. (127mm)
Knee Travel (Z-axis
manual)
19 3/4in. (502mm)
Ram Travel
16 8/9 in. (429mm)
Throat Distance (min.)
4
1
/
4
in. (171mm)
Throat Distance (max.)
28
1
/
4
in. (476mm)
Table to Spindle Nose
Gage line (min.)
3 2/7 in. (84mm)
Max. Weight of Workpiece
1100 lbs. (500 kgs.)
Table
Overall Sizes
11 3/4 x 59 in. (300 x
1500mm)
T-Slots
3 on 2
1
/
2
in. (64mm)
centers
T-Slot Size
5
/
8
in. (16mm)
Height above floor (max.)
52 in. (1321mm)
Milling
Feed Rate (Power
Optional)
Please see Chart
Space and Weight
Floor Area
7 x 10 ft. (2.1 x
3.1m)
Height
95 in. (2413mm)
Net Weight
4960 lbs. (2255kgs)
Shipping Weight
5181 lbs. (2355kgs)
Power
Electrical Supply – 60/50
Hz.
3 phase
220/230/380/415/
440/460/575V
Color
Standard
Machine Gray/ACER
White with Burgundy
Stripes
