Acer e-mill 3VS - Milling Head Specification

- 30 -
2-2 Milling Head Specification
Milling Head Specification
Model
3VS/3VSII/3VK
3VKH
5VK
6VK
Power
3 HP (2.25KW)
5 HP (3.75KW)
Motor RPM
1750
Speed Range RPM
Low
High
Variable Speed
0~520
0~560
500~4500
500~4500
Quill Travel
5" (127mm)
Quill Diameter
3.375" (86mm)
3.94" (100mm)
Spindle Taper
R 8
NST/ISO #40
Spindle Diameter
2.677" (68mm)
3.5" (89mm)
Spindle Feed Rate
0.0015"/rev. (0.038mm)
0.003/rev. (0.076mm)
0.006/rev. (0.152mm)
Drill Capacity
Manual Power
Ф 0.875" (22mm)
Ф 1.25"
(32mm)
Ф 0.37" (9.4mm)
Ф 0.625"
(16mm)
Boring Capacity
Ф 6" (125.4mm)
Ф 8" (200mm)
Milling Capacity
2.0 in
3
/min
2.5 in
3
/min
Spindle to Column
Minimum
Maximum
4" (101.6mm)
20" (508mm)
27" (685.8mm)
