Item # Description Item # Description
1 EMERGENCY STOP 11 QUILL STOP KNOB
2 RPM DIGITAL COUNTER 12 FEED CONTROL LEVER
3 FOR/REV SWITCH 13 QUILL
4 VARIABLE SPEED RESISTOR 14 SPINDLE
5 SPINDLE BRAKE HANDLE 15 MICROMETER ADJUSTING NUT & LOCKNUT
6 SPINDLE BRAKE LIMIT SWITCH 16 INDICATOR MOUNTING ROD
7 POWER FEED TRANSMISSION ENGAGEMENT CRANK 17 QUILL LOCK HANDLE
8 QUILL FEED SELECTOR 18 OIL CUP
9 MANAUL FEED HANDWHEEL 19 QUILL FEED HANDLE
10 FEED REVERSING KNOB 20 HI-NEUTRAL-LOW LEVER
21 SPINDLE MOTOR
