Item # Description Item # Description
1 EMERGENCY STOP 11 FEED CONTROL LEVER
2 RPM DIGITAL COUNTER 12 MICROMETER ADJUSTING NUT & LOCKNUT
3 FOR/REV SWITCH 13 QUILL
4 VARIABLE SPEED RESISTOR 14 SPINDLE
5 SPINDLE BRAKE HANDLE 15 INDICATOR MOUNTING ROD
6 SPINDLE BRAKE LIMIT SWITCH 16 QUILL LOCK HANDLE
7 POWER FEED TRANSMISSION ENGAGEMENT CRANK 17 QUILL FEED HANDLE
8 QUILL FEED SELECTOR 18 HI-NEUTRAL-LOW LEVER
9 MANAUL FEED HANDWHEEL 19 SPINDLE MOTOR
10 FEED REVERSING KNOB 20 QUILL STOP KNOB
