Acer e-mill 3VS - Page 60

- 59 -
Electric Component List
ACER Model:
Item # Description and function Suppliers Reference Technical data Supplier
1 TR1 Transformer LCP-TBS JY- 270 500VA 0-480V/0-110V LUNG GHI
2 SQ1 Supply disconnecting Switch ZH-C316 440V 15KA/16A KEDU
3 FU1 Fuse Blocks RT18-32X 3P -600V/32A CHANGXIN
4 FU2 Fuse Blocks TFB-102 250V/10A TEND
5 FU3 Fuse Blocks TFB-102 250V/10A TEND
6 FU1 Fuse 10*38*3P 500V-50KA/Am30a CHANGXIN
7 FU2 Fuse 30mm 30mm/5A TEND
8 FU3 Fuse 30mm 30mm/5A TEND
9 KM1 Spindle Magnetic Contactor CU-11/Coil 110V 230V/5HP/3KW TECO
10 KM2 Coolant Magnetic Contactor CU-11/Coil 110V 230V/5HP/3KW TECO
11 KM3 X-Y axis Magnetic Contactor CU-11/Coil 110V 230V/5HP/3KW TECO
12 KM4 Up Magnetic Contactor CU-11/Coil 110V 230V/5HP/3KW TECO
13 KM5 Down Magnetic Contactor CU-11/Coil 110V 230V/5HP/3KW TECO
14 FR1 Spindle Overload Relay TH-12 12-18A/230V(15A) TENYU
15 FR2 Coolant Overload Relay TH-12 0.9-1.5A/230V(0.9) TENYU
16 FR4 Up/down Overload Relay TH-12 7-10A/230V(7.6A) TENYU
17 X1 X2 X3 Terminal Blocks TB25-12P*3P 600V / 25A TEND
18 PB1 Emergency stop switch K2BS542 240V/3A/1B(R) CHANGXIN
19 PB2 Spindle start Switch K2BW33G1 240V/3A/1A(G) CHANGXIN
20 PB3 Spindle stopt Switch K2BA42 240V/3A/1B(R) CHANGXIN
21 PB4 X-Y axis stop Switch K2BW33G1 240V/3A/1B(R) CHANGXIN
22 PB5 X-Y axis start Switch K2BA42 240V/3A/1A(G) CHANGXIN
23 PB6 Up start Switch K2BA21 240V/3A/1A(BK) CHANGXIN
24 PB7 Down start Switch K2BA21 240V/3A/1A(BK) CHANGXIN
25 CS1 Coolant start/stop Switch K2BD21 240V/3A/1A(BK) CHANGXIN
26 HL Indicator Light NLD-22W AC-110V (W) NHD
27 LS1 Trip Spindle Limit Switch TZ7311 10A 250VAC TEND
28 LS2 Forward Limit Switch KZ-5109 250V 15A CHANGXIN
29 LS3 Reverse Limit Switch KM-1308 250V 15A CHANGXIN
30 LS4 Reverse Limit Switch KM-1308 250V 15A CHANGXIN
31 MS1 Spindle Motor 230V/460V 5HP 230V/460V 3.7KW ACER
32 MS2 Coolant Motor 230V/460V 1/8HP 230V/460V 0.93KW FLAIR
33 MS4 Up/down Motor 230V/460V 2HP 230V/460V 1.492KW JIN-SHIN
34 EL Halogen Light HT-L81+GS-20 24V/70W EGG
35 XS X-Y axis power feed LK 3021F 110V/2.5A SKYEY
36 E-STOP Emergency stop S04509-RWA800FPMT34 690V 10A 4KV Allen-Bradley
37 SB3 Emergency stop S04509-RWA800FPMT35 690V 10A 4KV Allen-Bradley
38 LIMIT SW Spindle Stop Limit Switch TZ7311 10A 250VAC TEND
39 LIMIT SW HI/LOW gear Limit Switch SHL-Q2255 AC-15 2A 125V 2A 125V OMRON
40 SB1 FORWARD SWITCH S04509-RWA800FPMT32 690V 10A 4KV Allen-Bradley
41 SB2 REVERSE SWITCH S04509-RWA800FPMT32 690V 10A 4KV Allen-Bradley
42 R.P.M METER RPM DIGITAL COUNTER PWRMMX-1-A13A DC0-10V 0~5300/660RPM PWR
43 V1 TOSHIBA S15 INVERTER VF-S15 230V/460V/3P/3.7KW
Toshiba
44 V1 FRN0020E2S-2GB FRN0020E2S-2GB 230V/460V/3P/3.7KW Fuji
45 R1 Braking Resistors ZQR450W 6.5Ω x 3 1350W
Toshiba
46 R1 Braking Resistors ZQR450W 11Ω x 3 1350W Fuji
47 TR 1 Single Phase Transformer 1Q24VA 24VA
Chen-Ten
Electronics
48 F1 Circuit Breaker 3A TEND
49 F2 Circuit Breaker 3A TEND
50 Power Relay Power Relay 110V
MY-2NJ+PYF-08A-E-T OMZ
5A 250VAC OMRON
51 Power On Power On Contactor C12D10D7 220V 3P 5.5HP NHD
52 CS2 Coolant On/Off Button 3P 10A 500V 2.2KW Suen-An
53 FAN Cooling Fan GA1123XBL AC110/120V 18/19W Gulf Electronics
54 B202 2K Variable Resistor B202 2K 2kΩ JASON
55 LUB 110V Lubrication Pump CESMA-2L 110V/0.1A/4W CHEN-YING
6VK 230/460V 5HP
