15
in using the IP address in the topology diagram to switch roles.
Note: When switching the role of an agent, make sure to power off the
controller first.
IV.
Mesh supports WPS Onboarding, but in cases where connection is hindered
due to environmental interference, it's recommended to move the agent closer
to the controller or restore the device to its factory default settings and follow
the Quick Setup process to reconfigure the agent.
Alternatively, you can perform the setup steps via Ethernet connection.
V.
If the Mesh Wi-Fi SSID or password is changed in an existing Mesh
network, agents will apply the new configuration after the synchronization
process is done. If the agent does not apply the new configuration successfully or
the agent is in the offline status, it must go through the onboarding process with
the controller again. This is necessary for the updated SSID or password to be
applied to these agents.
7. WAN
7.1
WAN Status
This tab provides details about WAN
connectivity status and the following
key information::
•
Time duration
(format HH:MM:SS)
•
MAC address
•
Connection Mode: DHCP,
static IP, PPPoE, etc.
•
IP address
•
Subnet mask
•
Default gateway
•
Primary & Secondary DNS server
7.2
WAN Setting:
On this page, you can configure the
Ethernet WAN connection mode to DHCP,
Static IP, or PPPoE, or switch the WAN
port to LAN1 based on your connection
needs. Click the dropdown arrow to reveal
and select your preferred WAN settings.
You can select “Switch WAN port to LAN1”
if you are using the router in repeater mode,
where the WAN port is not needed.
This will provide you with an additional
LAN port.
