MOUNTING AND WIRING 4-3
SB1391 Hardware and Setup Guide - Document revision no. 1.14
TABLE 4-2 Minimum recommended clearances
Location Clearance
Each side 10 mm (A in FIGURE 4-1)
Top and bottom 15 mm (B in FIGURE 4-1).
4.2. Wiring Diagram
Note
Connection to any other equipment (e.g., for supply, communications, data
processing, etc.) must be only to either Class III Type equipment or to equipment
that is approved for an applicable Low Voltage Directive standard.
Warning
Do not turn on the power while making connections. Doing so could result
in severe bodily injury or damage to the unit.
