5.5. Program Mode
Further information
More detailed information about ACSPL programming is contained in
the ACSPL Software Guide.
This section shows how to use ACS Debugger to:
♦ 1. Write a program
♦ 2. Download the program to the control unit
♦ 3. Run the program in trace mode
♦ 4. Run the program in fast mode
FIGURE 5-52 shows the parts of the main Debugger window.
FIGURE 5-52 Debugger main window
Program window displays
current program in
controller memory.
Trace window traces
program execution.
Program messages window
displays program output.
Watch window displays value of tagged
controller variables.
Toolbar – tool buttons
change depending on the
active window.
