MOUNTING AND WIRING 4-1
SB1391 Hardware and Setup Guide - Document revision no. 1.14
4. MOUNTING AND WIRING
TABLE 4-1 Topics covered in this chapter
Topic Description
Mounting Mounting guidelines, operating temperatures, front and side view
of the control unit, dimensions, and recommended clearances
Wiring diagram For quick understanding of the control unit connections
Power connections Wiring details for power connections (Drive supply, Control
supply, Motor, Regen, and Fan 24Vdc)
Control connections Wiring details for control connections (RS-232/433, CAN,
Encoder1+Hall/Resolver, Encoder2, I/O + Safety. and HSSI/PEG)
Indicators, Switches,
and Test Points
Functional description of the other elements of the control unit
front panel
4.1. Mounting
Mounting guidelines:
• Mount only on a well grounded surface.
• Do not mount units on top of each other.
• The support surface should be a rigid, non-vibrating object, such as, a wall or rack.
• Keep the environment free from corrosive chemical vapors, oil, steam, metal particles, moisture, or dust.
The ambient temperature must be maintained between +5 C and +45 C.
