WORKING WITH THE CONTROL UNIT 5-5
SB1391 Hardware and Setup Guide - Document revision no. 1.14
Action Effect of action
3. Insert disk 1 of the
Saver/Loader in the PC disk
drive.
The following ACS software tools will be added to the
ACS Tools program group.
• ACS Saver
• ACS Loader
5.2. Adjusting the Unit
The purpose of adjustment is to setup the module and to tune the control loops. The process is
carried out using ACS Adjuster.
An adjustment session consists of the following activities:
♦ 1. Establish communication with the unit.
♦ 2. Define amplifier and motor parameters for the specific motion application, set
protection parameters, and verify that the feedback subsystem is operating.
♦ 3. Tune the control loops through a series of interactive steps where the system is
excited by a signal and the response is monitored.
The order of operation is summarized in TABLE 5-4.
TABLE 5-4 Adjustment steps
Step Description
Setup
1.
Amplifier
parameters
Select amplifier from database list. Edit as necessary.
2.
Motor
parameters
Select motor from database list. Edit as necessary.
3.
Protection
parameters
Define limits. There are two sets. One for adjustment purposes and
one for regular operation.
4.
Feedback
verification
Verify that the feedback device and safety inputs are functioning
properly.
Tuning
5.
Current loop
adjustment
Tune the current filter while monitoring the current step response.
6.
Commutation
adjustment
Identify the relation between the position feedback device's reading
and the orientation of the magnetic field.
7.
Velocity loop
adjustment
Tune the velocity loop filters and parameters while monitoring the
velocity step response.
8.
Position loop
Tune the position loop gain while monitoring the response to a third
