WORKING WITH THE CONTROL UNIT 5-45
SB1391 Hardware and Setup Guide - Document revision no. 1.14
Action Effect of action
3. Click Yes Adjuster performs the actions stated and the Axis
Adjustment dialog box closes.
4. On the Application menu, click
Save.
The Application is written to the PC hard disk. This
is recommended as a backup precaution. Upon
successful save, a confirmation box is displayed
(FIGURE 5-46).
FIGURE 5-46 "Application saved to PC hard disk" confirmation
Action Effect of action
5. Click Yes. The confirmation box closes.
6. On the Application menu, click
Exit.
Adjuster closes.
Warning
If any safety devices were turned off during the adjustment session, they
should be turned back on upon session completion.
5.3. ACSPL Programming with ACS Debugger
Note
In the examples in this chapter, user input is shown as text in bold
capitals, for example, SXMO1. Input must be followed by pressing the
ENTER (or Carriage Return) key, which is indicated in the examples by
<cr>.
5.3.1. About ACSPL
ACSPL is the programming language for operating all ACS-Tech80, SB controllers and control
modules. ACSPL provides powerful, high-level motion control capabilities in a straightforward,
easy to use syntax. There are two modes for working with ACSPL:
• Direct mode: Commands are issued to the control module for immediate execution.
