5-46 WORKING WITH THE CONTROL UNIT
SB1391 Hardware and Setup Guide - Document revision no. 1.14
• Program mode: A program (sequence of commands) is stored in the control module's
nonvolatile memory for later execution.
ACS Debugger is a comprehensive ACSPL development environment. It enables both direct
mode and program mode operation.
Further information
More detailed information about ACSPL is contained in the ACSPL Software
Guide.
To illustrate the relationship between the ACSPL operation modes, TABLE 5-8 shows two
different ways to accomplish the following task:
Read the unit's current level, then set the current level to 55%.
TABLE 5-8 Two ways to read and set an ACSPL parameter
Method Report current level Set current level to 55%
Direct mode
Type RXCL and press carriage
return (Enter)
Type SXCL55 and press carriage
return (Enter)
Programming
mode
Add to program:
disp XCL
Add to program:
let XCL=55
5.3.2. Starting ACS Debugger
Note
It is recommended to use ACS Debugger's terminal for direct
communication with the control unit. However, any Windows terminal
application can also be used.
Action Effect of action
1. From the Windows Start menu,
point to the ACS Tools program
group and click ACS Debugger
The ACS Debugger window opens. Debugger
attempts to communicate with the control unit. If it
succeeds, the Communication parameter in the
status bar will read ON (FIGURE 5-47). If it fails,
verify that the communication parameters are set
correctly by clicking Communication on the
Settings menu.
