WORKING WITH THE CONTROL UNIT 5-65
SB1391 Hardware and Setup Guide - Document revision no. 1.14
5.6. Saving and Loading Control Unit Memory
ACS Saver saves a control unit's memory contents (including the adjustment values,
programming, program results, etc.) to a PC file. ACS Loader loads that file to another control
unit, ensuring that the two control units operate identically. ACS Saver/Loader greatly simplifies
the task of maintaining uniformity between control units.
Windows PC
Saver/
Loader
Hard disk
EPROM (firmware)
Controller 1
Adjustment
parameter
values
Nonvolatile read/write memory
Direct mode ACSPL
commands &
ACSPL program
Motion
control
algorithms
Filters
EPROM (firmware)
Controller 2
Adjustment
parameter
values
Nonvolatile read/write memory
Direct mode ACSPL
commands &
ACSPL program
Save entire contents of
Controller 1 memory
Load Controller 1 memory
contents to Controller 2
FIGURE 5-61 Saving and loading control unit memory contents
