ACTpro 1500 and 1520 Operating and Installation Manual
Page 39
ACTpro 1520 Electrical Specification
Input Voltage 230VAC +/- 10%
Frequency 50Hz
Input Fuse 625mA 250V anti-surge fuse
Output Voltage 13.65V (+/- 2%)
Max Load 2A
Electronic Output fuse Yes
Battery Current
≈ 0.5A for a battery discharged to ≈ 10V
Battery Protections Deep discharge/Over charge
Operating Tempature
Dimensions (H/W/D) 255mm/233mm/86mm
Weight 2.450Kg
Electrical
Physical
