ENGLISH
PSPIX² • User manual
23
- In the “Languages” menu, scroll through the languages until you fi nd the desired language. Click OK to
confi rm.
NOTE:
By default, the PSPIX network /IP adress confi guration is automatic (DHCP ON). If you wish to manually
allocate an IP address, click on the “Ethernet” icon
.
- In the “Ethernet” menu, click on the “DHCP Auto ON” icon, if you wish to manually allocate an IP address
to the PSPIX. This will switch this option off.
- Next click on the “Confi gure Fixed IP” button.
- The active number appears in orange color. Delete by pressing the
button, then type in the
desired fi xed IP address using the numerical keypad. Confi rm by pressing the OK button.
- Once all the fi elds are complete, confi rm by pressing the OK button, or cancel by pressing the red cross.
You will automatically return to the “Confi guration” menu.
- In the “Time” menu, you can set:
• “Eco mode” time: the time limit after which the light on the PSPIX system screen automatically dims due
to inactivity in order to save energy. By default it is set at 5 minutes. You can set it for time periods between
0 minutes and 60 minutes
• Set up the “Preview” time: the time for which the Preview of the image remains displayed on the screen
after reading an IP. By default it is set at 5 sec. You can set it for time periods between 0 minutes and 20
seconds.
- To do this, delete the digit by pressing the
button, then type in the desired time period with the
numeric keypad. Confi rm by pressing the OK button.
- Once all the fi elds are complete, confi rm by pressing the OK button, or cancel by pressing the red cross.
You will automatically return to the “Confi guration” menu.
Confi guration of the PSPIX in the acquisition module via the computer.
Please refer to the CD-ROM user manual supplied with the PSPIX system in the “Document” section.
