ENGLISH
PSPIX² • User manual
33
7.4 ERASING AN IP
After being read, the IP is automatically erased before falling into the IP receptacle of the PSPIX system.
However, it is necessary to erase an IP if it is the fi rst time it is used, if it has been stored for more than 24
hours, if it has been stored in a dark room or if the image data has not been deleted following a PSPIX system
malfunction. The “Erase” menu allows you to quickly and simply erase IPs.
NOTE:
During the erasure, no image is sent to the dental imaging software.
1. Click on the “Setup” icon
on the PSPIX system’s touch screen .
2. Next, click on the “Erase” icon
.
3. An animation will appear on the screen asking you to insert the IP to be erased.
Place the protective cover containing the IP in the PSPIX system’s insertion slot.
- vertically
- with the side containing the ACTEON logo facing towards you.
IP is automatically detected then enters the PSPIX system.
CAUTION:
Risk of PSPIX system malfunction. Only insert IPs into the PSPIX system. Do not insert any metal object,
protective cover or liquid into the IP insertion slot.
NOTE:
If the IP does not enter the PSPIX system this means that the IP has an alignment problem and it is not
correctly placed in the insertion slot (an animation on the Touch screen will ask you to correctly align
it). Therefore, correctly place the IP in the insertion slot.
4. An animation will appear on the screen showing the progress of the IP erasure.
5. Once the IP has been erased, it is automatically ejected into the IP receptacle, ready for a new operation.
Remove the IP, taking care to handle it by its edges.
6. The PSPIX system is now ready to erase the next IP (the animation on the screen asks you to insert a new
IP for erasure).
