Acteon PSPIX - Reading Imaging Plates (IPs)

ENGLISH
PSPIX² • User manual
28
7.3 READING THE IP
Single User Confi guration:
Please ensure that the PSPIX system is ready.
NOTE:
If the PSPIX system is operating in multi-user confi guration, refer to the following paragraph: “multi-
user confi guration”.
1. If the PSPIX acquisition module is not open, the Touch screen displays the single-user home page, which
displays the “PSPIX” logo and the time. To read an IP, check that your dental imaging software is open at the
correct patient fi le, and that the PSPIX acquisition module is also open.
2. If the connection is correct, the animation on the Touch screen asks you to insert the IP in the PSPIX
system. The patient’s name and dentist’s name are displayed on the screen.
Place the protective cover containing the IP in the insertion slot of the PSPIX system.
- vertically
- with the side containing the ACTEON logo facing towards you.
- with the open side of the protective cover facing towards the insertion slot.
The protective cover partially opens and the IP is automatically detected then enters the PSPIX system. The
protective cover remains in the insertion slot.
CAUTION:
Risk of PSPIX system malfunction. Only insert IPs into the PSPIX system. Do not insert any metal object,
protective cover or liquid into the IP insertion slot.
NOTE:
If the IP does not enter the PSPIX system this means that the IP has an alignment problem and it was not
correctly placed in the insertion slot (an animation on the Touch screen will ask you to correctly place
it). Therefore, correctly place the IP in the insertion slot.
3. Only remove the protective cover when it is empty.
4. An animation and a percentage will appear on the screen, showing the progress of the IP reading.
5. After several seconds, the digital image will appear simultaneously on the computer and PSPIX screen
